Product Details
Place of Origin: Shandong Province of China
Brand Name: YiZhi
Certification: CE / ISO
Model Number: YST380
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: USD 20000--60000
Packaging Details: film
Delivery Time: 50 days
Payment Terms: T/T
Supply Ability: 1 unit per 50 days
Power: |
160KW+22KW+2.2KW+0.8KW+0.8KW+0.75=187KW |
Oil Supply: |
Self Priming And Forced Oil Supply. |
Function: |
The Hydraulic Comprehensive Test Bench Can Test The Following Components: Main Tests: Single And Double Hydraulic Pumps; Open And Closed Hydraulic Pumps; Axial High-speed Hydraulic Motor, Etc. |
Driving Power: |
75-160KW |
Testing Method: |
Hydraulic Pump Test: The Main Driving Motor Drives The Tested Pump Filter To Extract Medium From The Hydraulic Oil Tank To Complete The Working Action. The Pressure Load Is Increased Or Decreased Through The Proportional Relief Valve At The Working Oil Por |
Pressure Loading: |
31 Mpa --42Mpa |
Purpose: |
For Repairing Hydraulic Pumps And Motors |
Warranty: |
1 Year |
Power: |
160KW+22KW+2.2KW+0.8KW+0.8KW+0.75=187KW |
Oil Supply: |
Self Priming And Forced Oil Supply. |
Function: |
The Hydraulic Comprehensive Test Bench Can Test The Following Components: Main Tests: Single And Double Hydraulic Pumps; Open And Closed Hydraulic Pumps; Axial High-speed Hydraulic Motor, Etc. |
Driving Power: |
75-160KW |
Testing Method: |
Hydraulic Pump Test: The Main Driving Motor Drives The Tested Pump Filter To Extract Medium From The Hydraulic Oil Tank To Complete The Working Action. The Pressure Load Is Increased Or Decreased Through The Proportional Relief Valve At The Working Oil Por |
Pressure Loading: |
31 Mpa --42Mpa |
Purpose: |
For Repairing Hydraulic Pumps And Motors |
Warranty: |
1 Year |
31-42Mpa, with computer, print test report , 75-160kw electric driving motor
The hydraulic test bench has a maximum flow rate of 500L/min, which makes it suitable for testing a wide range of hydraulic components, including single and double hydraulic pumps, open and closed hydraulic pumps, and axial high-speed hydraulic motors. It has a pressure loading capacity ranging from 31 Mpa to 42Mpa, which allows you to test the most demanding hydraulic components with ease.
The hydraulic comprehensive test bench has a power requirement of AC380V 400A, which provides sufficient power to run the machine efficiently. It is easy to operate, and the user-friendly interface allows you to set up and run tests quickly. The hydraulic tester comes with a one-year warranty, which gives you peace of mind knowing that you are making a reliable investment in your hydraulic system maintenance and repair work.
The hydraulic test bench is an essential tool for hydraulic system maintenance and repair work. It is designed to test a wide range of hydraulic components, including pumps and motors. The machine is versatile and reliable, allowing you to diagnose and troubleshoot hydraulic system problems quickly and accurately. The hydraulic tester has a maximum flow rate of 500L/min and a pressure loading capacity ranging from 31 Mpa to 42Mpa, making it suitable for testing the most demanding hydraulic components. It has a power requirement of AC380V 400A, which provides sufficient power to run the machine efficiently. The hydraulic test bench comes with a one-year warranty, giving you peace of mind knowing that you are making a reliable investment in your hydraulic system maintenance and repair work.
| Product Attribute | Value |
| Product Name | Hydraulic Test Bench |
| Printing Of Test Report | Yes |
| Rotation Speed | 0-3000 R/min Through Frequency Control |
| Power | 160KW+22KW+2.2KW+0.8KW+0.8KW+0.75=187KW |
| Warranty | 1 Year |
| Cooling Method | Air-cooled Radiator |
| Purpose | For Repairing Hydraulic Pumps And Motors |
| Emergency Stop Protection | Yes |
| Display Mode | Digital Display Of Speed, Flow, Pressure, Torque |
| Temperature Range | -10-60 ℃ |
| Function | The hydraulic comprehensive test bench can test the following components: Main tests: single and double hydraulic pumps; Open and closed hydraulic pumps; Axial high-speed hydraulic motor, etc. |
The hydraulic test bench product comes with comprehensive technical support and services to ensure optimal performance and longevity. Our team of highly trained technicians is available to assist with any questions or issues that may arise with the product. We offer troubleshooting guides, maintenance tips, and repair services to keep the hydraulic test bench running smoothly. In addition, we provide training and education for users to maximize the benefits of the product and ensure safe operation. Our commitment to customer satisfaction means that we are dedicated to providing exceptional support and services throughout the life of the product.
Q: What is the brand name of the hydraulic test bench?
A: The brand name is YiZhi.
Q: What is the model number of the hydraulic test bench?
A: The model number is YST380.
Q: Where is the hydraulic test bench manufactured?
A: The hydraulic test bench is manufactured in Shandong Province of China.
Q: What certifications does the hydraulic test bench have?
A: The hydraulic test bench is certified with CE and ISO.
Q: What is the minimum order quantity for the hydraulic test bench?
A: The minimum order quantity is 1 unit.
Q: What is the supply ability of the hydraulic test bench?
A: The supply ability is 1 unit per 50 days.
Q: What is the delivery time for the hydraulic test bench?
A: The delivery time is 50 days.
Q: What are the packaging details for the hydraulic test bench?
A: The packaging details are film.
Q: What is the price range for the hydraulic test bench?
A: The price range is USD 20000--60000.
Q: What are the payment terms for the hydraulic test bench?
A: The payment terms are T/T.
