Product Details
Place of Origin: Shandong Province of China
Brand Name: YiZhi
Certification: CE / ISO
Model Number: YST380
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: USD 20000--60000
Packaging Details: film
Delivery Time: 50 days
Payment Terms: T/T
Supply Ability: 1 unit per 50 days
Pressure Loading: |
31 Mpa --42Mpa |
Product Name: |
Hydraulic Test Bench For Repairing Construction Machines |
Testing Method: |
Hydraulic Pump Test: The Main Driving Motor Drives The Tested Pump Filter To Extract Medium From The Hydraulic Oil Tank To Complete The Working Action. The Pressure Load Is Increased Or Decreased Through The Proportional Relief Valve At The Working Oil Por |
Flow: |
≦ 500L/min |
Rotation Speed: |
0-3000 R/min Through Frequency Control |
Printing Of Test Report: |
Yes |
Main System Flow: |
550L+550L |
Pressure Loading: |
31 Mpa --42Mpa |
Product Name: |
Hydraulic Test Bench For Repairing Construction Machines |
Testing Method: |
Hydraulic Pump Test: The Main Driving Motor Drives The Tested Pump Filter To Extract Medium From The Hydraulic Oil Tank To Complete The Working Action. The Pressure Load Is Increased Or Decreased Through The Proportional Relief Valve At The Working Oil Por |
Flow: |
≦ 500L/min |
Rotation Speed: |
0-3000 R/min Through Frequency Control |
Printing Of Test Report: |
Yes |
Main System Flow: |
550L+550L |
Electric driving motor: 75kw--160kw
Pressure: 31.5Mpa-- 42Mpa
Speed: 0-1500r/min
Siemens PLC
HP Printer
Air cooling radiator
for repairing hydraulic pumps, motors, cylinders, valves
The hydraulic test bench has a digital display that shows the speed, flow, pressure, and torque of the hydraulic pump being tested. This digital display makes it easy to monitor and adjust the test parameters to ensure the optimal performance of the hydraulic pump. The hydraulic test stand has a power output of 160KW+22KW+2.2KW+0.8KW+0.8KW+0.75=187KW, which ensures that it can test even the most powerful hydraulic pumps with ease.
The hydraulic pump test bench has a self-priming and forced oil supply system that ensures a steady oil supply during testing. This oil supply system ensures that the hydraulic pump being tested receives a consistent oil supply, which is essential for accurate testing. The hydraulic test bench has a flow rate of ≦ 500L/min, which is more than enough for testing most hydraulic pumps.
The hydraulic test bench is a critical tool for any hydraulic pump manufacturer or repair shop. This hydraulic test rig is capable of testing a wide range of hydraulic pumps, making it a versatile and reliable testing machine. The hydraulic test stand is easy to use, and its digital display makes it easy to monitor and adjust the test parameters.
If you are looking for a high-quality hydraulic test bench, the hydraulic pump test bench is an excellent choice. This hydraulic test stand is a reliable and versatile testing machine that is capable of testing a wide range of hydraulic pumps. So, get your hands on the hydraulic test bench and take the performance and reliability of your hydraulic pumps to the next level.
| Product Name: | Hydraulic Test Bench for Repairing Construction Machines |
| Display Mode: | Digital Display Of Speed, Flow, Pressure, Torque |
| Power: | 187KW (160KW+22KW+2.2KW+0.8KW+0.8KW+0.75) |
| Purpose: | For Repairing Hydraulic Pumps And Motors |
| Rotation Speed: | 0-3000 R/min Through Frequency Control |
| Driving Power: | 75-160KW |
| Pressure Loading: | 31 Mpa --42Mpa |
| Printing Of Test Report: | Yes |
| Function: | The hydraulic comprehensive test bench can test the following components: Main tests: single and double hydraulic pumps; Open and closed hydraulic pumps; Axial high-speed hydraulic motor, etc. |
| Testing Method: | Hydraulic pump test: The main driving motor drives the tested pump filter to extract medium from the hydraulic oil tank to complete the working action. The pressure load is increased or decreased through the proportional relief valve at the working oil port of the tested pump. (Closed circuit pump requires auxiliary oil supply pump to be turned on) Axial high-speed hydraulic motor test: Conduct pump condition test with the same pump (auxiliary oil supply pump must be turned on) High speed hydraulic motor with balance valve function: The tested motor is subjected to shaft end loading test by the loading motor (used as a pump operating condition at this time). |
The YiZhi YST380 hydraulic pump test bench is a reliable and efficient testing equipment for hydraulic pumps and motors. It is manufactured in the Shandong province of China and is certified with CE and ISO certifications.
The hydraulic test stand is designed to test the performance of hydraulic pumps and motors. It is suitable for testing various types of hydraulic pumps, such as gear pumps, vane pumps, and piston pumps. This hydraulic pump test stand can also be used to test axial high-speed hydraulic motors and high-speed hydraulic motors with balance valve function.
The hydraulic pump test stand is suitable for various occasions and scenarios. It can be used in manufacturing plants, repair shops, and maintenance facilities. It is suitable for testing hydraulic pumps and motors for various applications, such as construction machinery, agricultural machinery, and industrial equipment.
The YiZhi YST380 hydraulic pump test bench has a rotation speed of 0-3000 R/min through frequency control. The equipment power requirement is AC380V 400A. The testing method involves hydraulic pump test, axial high-speed hydraulic motor test, and high-speed hydraulic motor with balance valve function test. The hydraulic test stand is equipped with an emergency stop protection system, which ensures the safety of the operator and the equipment.
The YiZhi YST380 hydraulic pump test bench is available for purchase with a minimum order quantity of 1 unit. The supply ability is 1 unit per 50 days, and the delivery time is 50 days. The packaging details include film. The price range for the hydraulic pump test stand is USD 20000--60000. Payment terms are T/T.
The YiZhi YST380 hydraulic pump test bench is a powerful and reliable testing equipment that can be used in various occasions and scenarios. It is an essential tool for manufacturing plants, repair shops, and maintenance facilities that deal with hydraulic pumps and motors.
The hydraulic test bench product comes with comprehensive technical support and services to ensure optimal performance and reliability. Our team of experienced technicians is available to provide assistance with installation, operation, and maintenance of the equipment. In addition, we offer on-site training for your staff to ensure proper use and handling of the product. Our customer support team is also available to address any questions or concerns you may have about the product. We are committed to providing top-notch technical support and services to ensure your satisfaction with our hydraulic test bench product.
Here are some frequently asked questions regarding YiZhi YST380 hydraulic test bench:
Q: What is the model number of the hydraulic test bench?
A: The model number is YST380.
Q: Where is the hydraulic test bench manufactured?
A: The hydraulic test bench is manufactured in Shandong Province of China.
Q: Does the hydraulic test bench come with any certifications?
A: Yes, the hydraulic test bench is CE and ISO certified.
Q: What is the minimum order quantity for the hydraulic test bench?
A: The minimum order quantity is 1 unit.
Q: What is the delivery time for the hydraulic test bench?
A: The delivery time is 50 days.
Q: What are the payment terms for the hydraulic test bench?
A: The payment terms are T/T.
Q: What is the supply ability for the hydraulic test bench?
A: The supply ability is 1 unit per 50 days.
Q: What is the pricing range for the hydraulic test bench?
A: The price range for the hydraulic test bench is USD 20,000 to USD 60,000.
Q: What is the packaging detail for the hydraulic test bench?
A: The packaging detail for the hydraulic test bench is film.
